A New Engine, a Future Classic
The V85 TT introduces a new Moto Guzzi engine. Its configuration mirrors that of all Moto Guzzi bikes in production today: an air-cooled transverse 90° V twin with OHV distribution and two valves per cylinder, the pride and tradition of the Mandello Eagle. Engine capacity is 853 cc, thanks to a bore to stroke ratio of 84 x 77 mm. The most modern of all engines in the range, it can boast a ratio of almost 100 HP/liter. Thanks to its complete new design and the use of materials generally destined for race bikes, such as titanium, the new "eight and a half" is able to deliver maximum power of 80 HP and boast an impressive maximum torque value of 80 Nm at 5,000 rpm, with 90% of the torque already available at 3,750 rpm, in keeping with the tradition of the Mandello twin, which has always offered excellent drive even at very low revs. This is the first Moto Guzzi small block engine that can easily reach 8000 rpm, an aspect that showcases its modern and exuberant nature.
The crankcase is the fruit of a new design and is stiffer, in order to fulfil its new role as a stress-bearing element in the frame, introducing new frame connections and strengthening elements in the internal stud bolt area. It also features new ports in order to check the oil level in the lower semi-crankcase. Lubrication involves a semi dry sump, with two coaxial pumps tasked with oil delivery and recovery that ensure excellent lubrication and do away with the need for an oil radiator, thus reducing the overall weight. The semi dry sump solution allows for a totally isolated crankcase chamber, preventing any power absorption that would occur with a dry sump system, where the piston also has to overcome the counter-pressure inside the sump. The oil circuit is totally new and features holes of different diameters, with one of the two pumps transferring lubricant from the crankcase chamber to the sump. The latter is reduced in size to increase ground clearance and allow for assembly of the protective aluminum under-sump. The whole crankshaft is new and, together with the piston rods, also new, allows for a reduction in weight of almost 30% with respect to other small block engines, upping throttle response speed while significantly reducing any vibration. The upper section of the twin engine is also totally new: in keeping with Moto Guzzi identity, OHV distribution with two valves per cylinder is retained, though the system and materials used are all new. Cylinders are of reduced height, while new and efficient oil passages and a brand-new fastening system to the crankcase ensure robustness and reliability. The heads have new special-shaped mix entry ducts and links. One of the stand-out aspects of a Moto Guzzi engine is its distribution, complete with aluminum roller cams and rocker arm pushrods. The use of 42.5 mm titanium intake valves, which weigh half of those in steel, has allowed for much more radical opening timing, to the benefit of maximum power. Low-profile pistons are used, with 20 mm pins, as well as new head and plug covers that differ in shape, while the flywheel and generator have been boosted. Injection makes use of a single 52 mm throttle body, while electronic management is entrusted to a multimap Ride-by-Wire throttle control, a solution that allows for delicate and scrupulous control of valve opening, not only optimizing overall efficiency for a smooth, rich delivery, but also saving on fuel. The new Moto Guzzi engine is in fact very frugal in terms of consumption: it has few components that absorb power (OHV distribution is one of the most frugal in terms of power absorption) and has no cooling circuit pump or long drive chains or belts.
Significant work has been done on the gearbox to make it smoother and more precise. The gearbox and clutch housing make for increased ground clearance; the dry clutch exploits a reinforcement disc under the clutch plate as well as a new clutch disc; a triple ring system is also introduced for the first time: a synchronizer that reduces gear noise to a minimum, particularly that of first gear. The ratios are new. In addition, the gears gain flexible coupling, for even smoother final transmission at the PTO shaft, this too new. Lastly, the swingarm housing zone is sized accordingly and features large diameter bearings.
First-Rate Technology and Content
For the V85 TT project to achieve its main goal, or rather to satisfy Guzzista in their daily riding as well as in their touring and adventurous off-road riding, Moto Guzzi has designed a complete range of standard electronic equipment, without any inopportune technological overload, for maximum travel enjoyment. To make life on board easier and safer, Moto Guzzi introduces three different riding modes on the V85 TT: Road, Rain and Off-road. Each of these Riding Modes corresponds to a different engine mapping and a different ABS and MGCT traction control calibration, as well as a different response from the Ride-by-Wire accelerator control:
- Road: designed for smooth riding while still retaining an element of fun. Foresees a medium level of MGCT traction control calibration, ABS active on both channels and a prompt throttle response.
- Rain: ideal in situations of reduced grip, to ensure maximum safety while riding. Foresees a higher level of traction control calibration, ABS active at both wheels and a gentler throttle response.
- Off-road: the setting for the all-terrain soul of the V85 TT, designed to make the most of the chassis and engine during off-road exploits. Foresees the lowest level of traction control intervention, ABS only active at the front wheel with dedicated calibration (and with the possibility to deactivate it at the front wheel), along with a gentler throttle response assisted by greater engine braking.
The rider need only select the preferred mode, safe in the knowledge that Moto Guzzi has developed the best possible electronic configuration for each Riding Mode.
V85 TT is also equipped with Cruise Control, so that a pre-set speed can be maintained without acting on the accelerator. This system is also designed to make a rider's journey easier, just one button needed to activate and engage the system and increase/reduce the set speed.
All travel parameters can be controlled via the digital instrument cluster complete with TFT display. The background and color of the characters adapt to different light conditions thanks to a built-in sensor. The information displayed, in addition to the classic speedometer, rev counter, mileage counter and clock, also includes selected gear indices, air temperature, fuel level, average and current consumption, residual autonomy and selected Riding Mode. It is also possible to set a maximum number of revs for the gear shift light sensor, useful when running in the bike or seeking to limit fuel consumption as far as possible. Alongside the display is a USB port while provision is made for a second port under the seat.
Moto Guzzi V85 TT presents MIA, the new Moto Guzzi multimedia platform that allows a smartphone to be connected to the vehicle (via an ECU available in the rich catalogue of Moto Guzzi accessories), thus extending instrument functionality. MIA can be used to reproduce music and make/receive phone calls with the use of a helmet intercom. It also introduces a navigation function for the first time, allowing the rider to find and set a destination and view directions in the form of intuitive pictographs on the instrument cluster.
The Moto Guzzi Off-Road Tradition
Moto Guzzi boasts a solid off-road tradition: initial proof of this came at the Six Day Reliability Trial in 1939, which took place in Austria, where Moto Guzzi participated with the GT 20, winning four gold medals. This reliability trend continued in 1957, with the Lodola Regolarità, and then with the Stornello Regolarità in 1962. Moto Guzzi bikes have participated in various editions of the Paris-Dakar, albeit in an unofficial capacity, thanks to race versions prepared on the request of Guzzisti. Already present at the first 1979 edition with a modified V50, rider Bernard Rigoni managed to finish the race mid-field, a very positive result considering that the classification combined both cars and bikes at that time. Moto Guzzi motorcycles immediately earned the respect of the other manufacturers involved, due to the speed-related performance achieved by the 90° transverse V twin together with its reduced fuel consumption and excellent chassis stability. It went on to compete again in 1980 and 1981, though its most famous appearances are those of 1985 and 1986, owing to the great passion and dedication of a Guzzista architect called Claudio Torri, who commissioned the Mandello Test Department with building a very special V65 TT. The engine was based on that of the V65, tuned to 55 HP; the frame was significantly strengthened, while suspension was specifically configured for off-road usage. The original fuel tank was replaced with a 50-liter aluminum tank, while the swingarm was taken from the sporty Le Mans 1000. The bike behaved well, so much so that the French importer requested 16 units to sell to private riders for use during subsequent seasons; at the same time the importer also asked Moto Guzzi to develop a new model, based on the more high-performance V75 with four valve timing. The V75 TT was accredited with 62 HP that allowed for a top speed in excess of 170 Km/h. Both bikes are part of a collection of more than 150 models exhibited at the Moto Guzzi museum in Mandello del Lario.
A Vast Range of Accessories, Designed and Created by Moto Guzzi
The V85 TT is designed to be equipped with a series of original accessories, to amplify the touring vocation of this adventurous enduro.
All accessories are conceived, designed and produced by Moto Guzzi. They are all homologated and subjected to strict control test cycles just like any other original part on the bike in order to guarantee a long-lasting and high-quality product.
Pair of side panniers: created in 1.5 mm aluminum, they are ultra-resistant and spacious (33-litre left pannier; 39-liter right pannier). The panniers are powder painted to offer maximum protection and durability over time. They are locked to the bike using a dedicated safety key and can be easily removed in just a few seconds. Additional lock blocks are supplied in order to be able to use just one key also for the 41-liter case. Opening from the top facilitates loading. Stainless steel supports are included in the kit. Internal bags and a thermoformed tray are available as accessories.
41-liter aluminum case: created in 1.5 mm aluminum, it is ultra-resistant and spacious. The case is powder painted to offer maximum protection and durability over time. It is locked to the bike using a dedicated safety key and can be easily removed in just a few seconds. Complete with stainless steel fastening plate.
Larger windscreen: offers the rider greater protection during long trips. The anti-impact, scratch-proof polycarbonate sheet guarantees safety while ensuring that transparency and shine will remain unaltered over time.
Center stand: created in cataphoretic and powder coated steel to stand up to different weather conditions, it has been designed and engineered to meet with the strictest safety and resistance standards.
Larger stand base: created in anodized steel to stand up to different weather conditions, it is designed to offer a greater support surface area on irregular and uneven ground.
Öhlins shocks: with adjustable compression, rebound and spring preload, they offer maximum comfort and safety in all situations.
Moto Guzzi exhaust by Arrow: homologated in titanium with a heat protection cover, support clamp and carbon end cap. It reduces the weight and makes for a unique and aggressive sound.
Shaft drive protection: Created with very thick steel tubes, it protects the shaft drive in case of a crash.
Tubular engine guard bar: Created with very thick steel tubes, it specifically protects the engine and the rider's legs.
Comfort seats: a complete range of seats that increase comfort levels thanks to a special 3D insert. Available in three different heights.
Clutch and brake lever: machined from solid, they improve ergonomics by offering four-position adjustment.
Additional LED lights: with an aluminum body and contained size, the lights use limited power. They integrate perfectly with the bike and allow for greater visibility and safety during night-time riding.
Foldaway mirrors: They fold in on themselves towards the handlebar, to reduce bulk during off-road use.
Mudguard: Created in injected plastic material, it is mounted on the shaft drive and protects the engine from stones and water.
Sport Adventure tires: Michelin Anakee Adventure, as standard on special versions.
High grip brake pedal: laser-cut and power painted in a resistant material. Ensures perfect grip even in the most extreme situations.
Moto Guzzi Multi-media Platform: the new device that allows for a smartphone to be connected to the bike, transforming it into a real multimedia platform.
Electronic anti-theft system: comprises a compact and technologically advanced ECU that is easy to install. Complete with remote control. The system is self-powered with minimum energy absorption.
Light protection: an anti-impact, scratch-proof polycarbonate sheet. Protects the light from any impact or accidental damage. Particularly useful on off-road routes.
Tool bag: created in leather, it can be affixed to the luggage rack with screws. Practical for keeping all those tools needed for an emergency repair (tools not included).
